DESCRIPTION AND OPERATION
HEATED SEATS DESCRIPTION AND OPERATION
Heated Seats System Operation
The driver and front passenger seats are heated using electric heater elements located in the seat
cushions and seat backs. The heated seat control module is part of the seat cushion element and
harness assembly and controls the battery positive voltage used to supply the seat heater elements.
The heated seat switch and a thermistor located in the seat cushion are connected in series and
provide a single input to the heated seat control module. Ignition voltage is supplied to the heated
seat switch from the HVAC 20A fuse in the underhood BEC. When the heated seat switch is in
the high or low positions voltage is supplied through one of the internal resistors to the switch
signal circuit. The heated seat switch signal circuit is grounded through the seat cushion
thermistor which is a temperature sensitive variable resistor. The heated seat switch signal circuit
input to the heated seat control module is spliced from the circuit between the switch and the
1. Remove the front bucket seat. Refer to Front Seat Replacement - Bucket .
2. Remove the seat back recliner handle. Refer to Driver Seat Recliner Handle and
Passenger Seat Recliner Handle Replacement .
3. Remove the front seat trim panels. Refer to Front Seat Trim Panel Replacement
(Manual Lumbar) or Front Seat Trim Panel Replacement (Power Lumbar) .
1
Seat Cushion Cover
Procedure
1. Disconnect the seat cover J-channel from the seat cushion frame.
2. Remove the hog rings that secure the pad to the cushion cover.
2
Seat Cushion Heater
Tip:
On the driver seat peel the heater from the seat cushion and disconnect
the electrical connector.
On the passenger seat the heater must be replaced as a kit with the
passenger presence system.
3
Seat Cushion Pad
Tip: Re-zero the inflatable restraint passenger presence system whenever the
seat cushion or any component of the passenger presence system is removed.
Refer to Control Module References .
