Hummer H3. Manual - part 1305
2007 BRAKES
Hydraulic Brakes - H3
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
Fastener Tightening Specifications
BRAKE SYSTEM SPECIFICATIONS
Brake System Specifications
Application
Specification
Metric
English
Brake Hose to Caliper Bolt, Front
40 N.m
30 lb ft
Brake Hose to Caliper Bolt, Rear
40 N.m
30 lb ft
Brake Pedal Bolt
27 N.m
20 lb ft
Brake Pipe Fittings
19 N.m
14 lb ft
Brake Pipe Fittings, Power Brake Booster Outlet
Front Pipe
15 N.m
11 lb ft
Front Brake Caliper Bleed Screw
11 N.m
97 lb in
Front Brake Hose Bracket Bolt
9 N.m
80 lb in
Hose Bracket to Anchor Plate Bolt
25 N.m
18 lb ft
Hose Bracket to Frame Bolt
12 N.m
106 lb in
Hose Bracket to Knuckle Bolt
12 N.m
106 lb in
Hose Bracket to Rear Axle Bolt
22 N.m
16 lb ft
Hose Bracket to Steering Knuckle
9 N.m
80 lb in
Hose Bracket to Upper Control Arm Bolt
9 N.m
80 lb in
Master Cylinder Mounting Nuts
30 N.m
22 lb ft
Master Cylinder Reservoir Bolt
2 N.m
18 lb in
Power Brake Booster Pump Bolts
8 N.m
71 lb in
Power Brake Booster Pump Motor Wire Retaining
Screws
3 N.m
27 lb in
Rear Brake Caliper Bleed Screw
10 N.m
89 lb in
Rear Brake Hose Bracket to Jounce Bumper Bolt
9 N.m
80 lb in
Rear Brake Hose to Frame Bolt
2 N.m
17 lb in
