6. Inflate the tire to the proper air pressure.

7. Ensure that the locating rings are visible on both sides of the tire in order to verify that the tire bead is

fully seated on the wheel.

TIRE ROTATION

Removal Procedure

In order to equalize wear, rotate the tires at the specified intervals. Refer to Scheduled Maintenance in
Maintenance and Lubrication. In addition to scheduled rotation, rotate the tire and wheel assembly whenever
you notice uneven tire wear.

Radial tires tend to wear faster in the shoulder area, particularly in front positions, due to design. Radial tires in
non-drive locations may develop an irregular wear pattern that can generate tire noise. This especially makes
regular tire rotation necessary.

1. If the spare tire is to be included in the rotation, remove it from the vehicle.

2. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle in General Information.

3. Remove the 4 center caps from the wheels.

4. Remove the lug nuts from all of the 4 wheels.

the beads, deflate, relubricate the beads and reinflate. Overinflation
may cause the bead to break and cause serious personal injury.



2004 Hummer H2

2004 SUSPENSION Tires and Wheels - Hummer H2



Fig. 9: Rotating Tires (5 Tires)
Courtesy of GENERAL MOTORS CORP.

5. Including the spare tire, rotate the 5 tires as shown.



2004 Hummer H2

2004 SUSPENSION Tires and Wheels - Hummer H2



Fig. 10: Rotating Tires (4 Tires)
Courtesy of GENERAL MOTORS CORP.

6. Excluding the spare tire, rotate the 4 tires as shown.

Installation Procedure



2004 Hummer H2

2004 SUSPENSION Tires and Wheels - Hummer H2



Fig. 11: Installing Wheel Nuts
Courtesy of GENERAL MOTORS CORP.

1. Install the lug nuts. Tighten each wheel in the sequence shown.

Tighten: Tighten the lug nuts to 190 N.m (140 lb ft).

2. Install the 4 center caps.

3. Lower the vehicle.

SPARE TIRE CARRIER REPLACEMENT

Removal Procedure

1. Remove the spare tire cover.

2. Remove the spare tire mounting nut (3), washer, and mounting plate (4).

3. Remove the spare tire (5) from the spare tire carrier (1).

NOTE:

Refer to Fastener Notice in Cautions and Notices.



2004 Hummer H2

2004 SUSPENSION Tires and Wheels - Hummer H2
