12 14-197 B 19. Connect the negative battery terminal to A/T clutch pressure control solenoid valve B connector 20. Disconnect one of the battery terminals, and check valve movement at the fluid passage in the valve 21. Clean the mounting surfaces and fluid passages of the solenoid valve body and solenoid valve cover. 22. Install a new solenoid valve body gasket on the solenoid valve cover, and install the ATF pipes with 23. Install A/T clutch pressure control solenoid valves A and B. 24. Install the harness cover on the cover bracket, and secure it with the bolt. 25. Check the connectors for rust, dirt, or oil, clean or repair if necessary, then connect the connectors 26. Attach the shift cable end to the control lever, then insert the control pin into the control lever hole 27. Secure the shift cable bracket with the nuts. 28. Install the battery base bracket and the battery base. 29. Install the air cleaner housing, the resonator, the intake air duct, and the intake manifold cover. 30. Install the battery tray, the battery, and the battery hold-down bracket, then connect the battery cables. 31. Enter the anti-theft codes for the audio system and the navigation system (if equipped). Set the clock 32. Do the power window control unit reset procedure (see page 22-209). |
