Fig. 54: ECM/PCM Circuit Diagram (3 Of 12)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE Fuel and Emissions Systems - Element

Fig. 55: ECM/PCM Circuit Diagram (4 Of 12)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE Fuel and Emissions Systems - Element

Fig. 56: ECM/PCM Circuit Diagram (5 Of 12)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE Fuel and Emissions Systems - Element

Fig. 57: ECM/PCM Circuit Diagram (6 Of 12)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE Fuel and Emissions Systems - Element
