LEFT REAR DOOR SUBHARNESS

CONNECTOR TO HARNESS INDEX

Fig. 21: Identifying Left Rear Door Wire Harness

door

G771

6



Left rear
door

Body ground, via left rear door wire
harness



Connector or

Terminal

Ref Cavities

Location

Connects to

Notes

C554

1

6

Left quarter
panel

Floor wire harness (see FLOOR WIRE
HARNESS (LEFT BRANCH) )



C771

2

6

Left rear door Left rear door wire harness





2007 Honda Element EX

2007-2008 ELECTRICAL Connectors and Harnesses - Element



Courtesy of AMERICAN HONDA MOTOR CO., INC.

RIGHT REAR DOOR WIRE HARNESS

CONNECTOR TO HARNESS INDEX

RIGHT REAR DOOR SUBHARNESS

CONNECTOR TO HARNESS INDEX

Connector or Terminal Ref Cavities

Location

Connects to

Notes

Front passenger's door
switch

1

1

Right rear
door





Right rear door lower
switch

2

2

Right rear
door





Right rear door speaker

6

2

Right rear
door





Right rear door upper
switch

3

2

Right rear
door





C761

4

6

Right rear
door

Right rear door subharness



G751

7



Right rear
door

Body ground, via right rear door wire
harness



Connector or

Terminal

Ref Cavities

Location

Connects to

Notes

C556

5

6

Right quarter
panel

Floor wire harness (+see FLOOR WIRE
HARNESS (RIGHT BRANCH) )



C761

4

6

Right rear
door

Right rear door wire harness





2007 Honda Element EX

2007-2008 ELECTRICAL Connectors and Harnesses - Element



Fig. 22: Identifying Right Rear Door Wire Harness
Courtesy of AMERICAN HONDA MOTOR CO., INC.

A/C WIRE HARNESS

CONNECTOR TO HARNESS INDEX

Connector or

Terminal

Ref Cavities

Location

Connects to

Notes

Air mix control
motor

1

7

Under left
side of dash





Blower motor

4

2

Under right
side of dash





Blower power
transistor

5

4

Under right
side of dash





Evaporator
temperature sensor

9

2

Under left
side of dash







2007 Honda Element EX

2007-2008 ELECTRICAL Connectors and Harnesses - Element



Fig. 23: Identifying A/C Wire Harness
Courtesy of AMERICAN HONDA MOTOR CO., INC.

ODS UNIT HARNESS

CONNECTOR TO HARNESS INDEX

Mode control
motor

2

7

Behind glove
box





Recirculation
control motor

3

7

Behind glove
box





C851

7

21

Behind glove
box

Dashboard wire harness A (see DASHBOARD
WIRE HARNESS A (RIGHT BRANCH) )



C852

6

1

Behind glove
box

Dashboard wire harness A (see DASHBOARD
WIRE HARNESS A (RIGHT BRANCH) )



C853

8

1

Under middle
of dash

Engine compartment wire harness (see ENGINE
COMPARTMENT WIRE HARNESS
(DASHBOARD) )



Connector or Terminal Ref Cavities

Location

Connects to

Notes

Inner side front
passenger's weight
sensor

4

2

Under front
passenger's seat







2007 Honda Element EX
