Fig. 590: Removing Roller Bearing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Install the new roller bearing in the transfer holder with the driver and 62 x 68 mm attachment.

Fig. 591: Identifying Roller Bearing And Transfer Holder With Driver
Courtesy of AMERICAN HONDA MOTOR CO., INC.

TRANSFER HOLDER TAPERED ROLLER BEARING OUTER RACE
REMOVAL/INSTALLATION

Special Tools Required



Driver 07749-0010000



Attachment, 72 x 75 mm 07746-0010600

1. Remove the tapered roller bearing outer race (A) and 75 mm thrust shim (B) from the transfer holder.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 592: Removing Tapered Roller Bearing Outer Race
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Install the 75 mm thrust shim (A) in the transfer holder, then install the tapered roller bearing outer race

(B) with the driver and 72 x 75 mm attachment.

Fig. 593: Pressing Tapered Roller Bearing Outer Race With Driver
Courtesy of AMERICAN HONDA MOTOR CO., INC.

TRANSFER DRIVE GEAR BEARING REPLACEMENT

Special Tools Required



Driver 07749-0010000



Attachment, 37 x 40 mm 07746-0010200



Attachment, 52 x 55 mm 07746-0010400

1. Remove the tapered roller bearing (A) from the transfer drive gear (B) with the driver and 37 x 40 mm



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



attachment, bearing separator (C) and a press.

Fig. 594: Removing Tapered Roller Bearing With Driver
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Install the new tapered roller bearing (A) on the transfer drive gear (B) with the driver and 52 x 55 mm

attachment, and a press.

Fig. 595: Installing Tapered Roller Bearing With Driver
Courtesy of AMERICAN HONDA MOTOR CO., INC.

TRANSFER OUTPUT SHAFT BEARING REMOVAL/INSTALLATION

Special Tools Required



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element





Driver, 40 mm I.D. 07746-0030100



Attachment, 35 mm I.D. 07746-0030400

1. Remove the tapered roller bearing (A) from the transfer output shaft (B) with a bearing separator (C) and

a press. Place a shaft protector (D) between the transfer output shaft and the press to prevent damaging
the transfer output shaft.

Fig. 596: Placing Shaft Protector Between Transfer Output Shaft
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Install the 35 mm thrust shim (A) on the transfer output shaft (B).

Fig. 597: Identifying Tapered Roller Bearing And Transfer Output Shaft With Driver
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Install the tapered roller bearing (C) on the transfer output shaft with the 40 mm driver, 35 mm



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element
