Fig. 232: Identifying Front Subframe Mounting Bolts Position
Courtesy of AMERICAN HONDA MOTOR CO., INC.

31. Attach the front subframe adapter (VSB02C000016) to the front subframe with hanging the hook of the

front subframe adapter (VSB02C000016) over the front of the front subframe, then tighten the wing nut.

Fig. 233: Identifying Front Subframe Adapter (VSB02C000016)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

32. Raise the jack and line up the slots in the arms with the bolt holes on the corner of the jack base, then

attach them with the bolts securely.

33. Remove the four front subframe mounting bolts, then lower the front subframe.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 234: Identifying Front Subframe Mounting Bolts
Courtesy of AMERICAN HONDA MOTOR CO., INC.

34. 4WD: Make a reference mark (A) across the propeller shaft (B) and the transfer companion flange (C),

then separate the propeller shaft from the transfer assembly.

Fig. 235: Identifying Propeller Shaft And Transfer Companion Flange Mounting Bolts
Courtesy of AMERICAN HONDA MOTOR CO., INC.

35. Pry the left driveshaft out of the differential (see step 9 in FRONT DRIVESHAFT REMOVAL ).

36. Remove the driveshafts from the differential and intermediate shaft.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 236: Identifying Intermediate Shaft
Courtesy of AMERICAN HONDA MOTOR CO., INC.

37. Remove the intermediate shaft cover (A).

Fig. 237: Identifying Intermediate Shaft Cover
Courtesy of AMERICAN HONDA MOTOR CO., INC.

38. Remove the intermediate shaft (B). Coat all precision finished surfaces with clean engine oil, then tie

plastic bags over the driveshaft and intermediate shaft ends.

39. Place a jack under the transmission.

40. Remove the transmission housing upper mounting bolts.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 238: Identifying Transmission Housing Upper Mounting Bolts
Courtesy of AMERICAN HONDA MOTOR CO., INC.

41. Remove the transmission mount bracket bolt (A) and nuts (B), then remove the transmission mount bolt

(C).

Fig. 239: Identifying Transmission Mount Bracket Bolt And Nuts
Courtesy of AMERICAN HONDA MOTOR CO., INC.

42. Remove the transmission housing front mounting bolts located on front lower of the transmission.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element
