YES -Check for intermittent short to body ground in the wire between shift solenoid valve D and the NO -Go to step 21. 21. Monitor the OBD STATUS for P0982 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES -Troubleshooting is complete. If any other DTCs were indicated in step 20, go to the indicated NO -If the screen indicates FAILED, check for intermittent short to body ground in the wire between 22. Update the PCM if it does not have the latest software (see UPDATING THE PCM ), or substitute a known-good PCM (see SUBSTITUTING THE PCM ). 23. Start the engine in the P position, and wait for at least 1 second. 24. Drive the vehicle in 2nd gear in the D position for at least 1 second. 25. Check for DTCs with the HDS. Is DTC P0982 indicated? YES -Check for intermittent short to body ground in the wire between shift solenoid valve D and the NO -Go to step 26. 26. Monitor the OBD STATUS for P0982 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the NO -If the screen indicates FAILED, check for intermittent short to body ground in the wire between DTC P0983: OPEN IN SHIFT SOLENOID VALVE D CIRCUIT NOTE:
2007 Honda Element EX 2007-2008 TRANSMISSION Automatic Transmission - Element
|
