Fig. 41: Identifying Lower Slide Shaft With Wire Between Joint Yokes 8. Release the lock lever, and adjust the steering column to the full telescopic out position, then tighten the lock lever. 9. Remove the steering joint bolt (A), and disconnect the steering joint by moving the steering joint (B) toward the column.. Fig. 42: Identifying Steering Joint Bolt 10. Remove the center guide (A) (if equipped), and discard it. The center guide is for factory assembly only.
2008 Honda Civic EX 2006-08 STEERING Hydraulic Power Steering Components - Civic (All Except Hybrid)
|
