Fig. 189: Identifying Carrier Bearings And Bearing Puller
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Install the new bearings (A) with the 40 mm I.D. driver (B) and a press. Press

each bearing on until it bottoms. There should be no clearance between the
bearings and the carrier.

NOTE:

Place the seal (C) part of the bearing towards the
outside of the differential, and install it.

2008 Honda Civic LX

2006-08 TRANSMISSION Manual Transmission (6-Speed)(Except Hybrid) - Civic

Fig. 190: Identifying Bearings, I.D. Driver And Seal
Courtesy of AMERICAN HONDA MOTOR CO., INC.

OIL SEAL REPLACEMENT

Special Tools Required

Oil seal driver attachment 07NAD-P20A100

Driver 07749-0010000

1. Remove the oil seal (A) from the transmission housing (B).

2008 Honda Civic LX

2006-08 TRANSMISSION Manual Transmission (6-Speed)(Except Hybrid) - Civic

Fig. 191: Identifying Oil Seal And Transmission Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Remove the oil seal (A) from the clutch housing (B).

Fig. 192: Identifying Oil Seal And Clutch Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Install the new oil seal in the transmission housing with the driver (A) and oil

seal driver attachment (B).

2008 Honda Civic LX

2006-08 TRANSMISSION Manual Transmission (6-Speed)(Except Hybrid) - Civic

Fig. 193: Identifying Driver And Oil Seal Driver Attachment
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Install the new oil seal in the clutch housing with the driver (A) and oil seal

driver attachment (B).

Fig. 194: Identifying Driver And Oil Seal Driver Attachment
Courtesy of AMERICAN HONDA MOTOR CO., INC.

DIFFERENTIAL THRUST CLEARANCE ADJUSTMENT

Special Tools Required

Driver, 40 mm I.D. 07746-0030100

1. If you removed the 80 mm shim from the transmission housing, reinstall the

same sized shim.

Fig. 195: Identifying Shim
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2008 Honda Civic LX

2006-08 TRANSMISSION Manual Transmission (6-Speed)(Except Hybrid) - Civic
