cleaning, keep oil, grease and water from getting on the clean surface. 10. If the old windshield will be reinstalled, use a putty knife to scrape off the old adhesive, the fasteners and the rubber dam from the windshield. Clean the 11. Attach the upper rubber dam (A), side rubber dam (B), and clips (C) with adhesive tape to the inside face of the windshield (D) as shown in Fig. 8: Be sure the rubber dam and clips line up with the alignment marks (E). Be sure the convex portion (F) of the left and right clips toward left. Be careful not to touch the windshield where adhesive will be applied. Rubber dams adhesive tape: Thickness 0.16 mm (0.006 in.) Clips adhesive tape: Thickness 0.4 mm (0.016 in.)
2008 Honda Civic EX 2006-08 ACCESSORIES & EQUIPMENT Glass - Civic (All Except Hybrid)
|
