locations (see LIFT AND SUPPORT POINTS ). 3. Remove the front wheels. careful not to damage the pin boot, and pivot the caliper (C) up out of the way. Fig. 29: Removing Flange Bolt Holding Caliper Pin With Wrench 5. Remove the pad shims (A) and brake pads (B). Fig. 30: Removing Pad Shims And Brake Pads
2008 Honda Civic GX 2006-08 BRAKES Conventional Brake Components - Civic (Except Hybrid)
|
