Fig. 12: Identifying Arrow Mark On Cable Reel Label 2. Position the two tabs (A) of the turn signal cancelling sleeve (B) as shown. Install the steering wheel on to the steering column shaft, making sure the Fig. 13: Identifying Steering Wheel On Steering Column Shaft 3. Install the steering wheel bolt (A), and tighten it to the specified torque. Connect the cable reel subharness connector (B). Make sure the wire harness is
2008 Honda Civic EX 2006-08 STEERING Steering - Civic (All Except Hybrid)
|
