13. Measure the resistance between the No. 3 terminal of SRS unit connector B (28P) and body ground, and between the No. 4 terminal and body ground. Fig. 105: Measuring Resistance Between No. 3 Terminal Of SRS Unit Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and NO -Short to ground in the floor wire harness; replace the floor wire harness. DTC 27-1X ("X" CAN BE 0 THRU 9 OR A THRU F): OPEN IN DRIVER'S SEAT BELT BUCKLE Special Tools Required SRS inflator simulator 07SAZ-TB4011A SRS simulator lead K 070AZ-SNAA200 NOTE: Before doing this troubleshooting procedure, review SRS
2008 Honda Civic EX 2006-08 RESTRAINTS SRS (Supplemental Restraint System) - Civic (Except Hybrid)
|
