Appendix A-9
Viewing confirmation
backup door
backup door glass
Wash, base-coat and stick according to the corresponding positions showed
by the broken line in the Figure
Apply washer on the glass-sticking
region of the backup door
Viewing confirmation
Viewing confirmation
Shake the glass base-coater to be sufficiently even followed
by the even application on the glass frame with the width of
about 20 and dry it for 2-15 minutes
Viewing confirmation
Viewing confirmation
Evenly apply it on the sticking region with the width of about
25mm and volatilize it completely.
Shake the base-coater to be sufficiently even followed by the
even application on the sticking region with the width of
about 20mm and dry it for 2-15 minutes
Wash the glass frame with the width of about 25mm and
volatilize the washer
Apply base-coater on the glass-
sticking region of the backup door
Apply washer on the backup door
glass frame
Apply base-coater on the backup
door glass frame
Apply adhesive on the backup door
glass frame
Backup door glass fixing
Instantly install and fix the glass after the glass adhesive
application
Vertically apply the glass adhesive on the glass frame and make
it even, continuous. Height: 12mm, width: 8mm
Vi e w i n g / h a n d l e
confirmation
