Geely Emgrand X7. Manual part - 20
The pressure of compressed air can not exceed 205kPa (29.75 psi). 2. Let an assistant bring the air hose into the vehicle. 3. Let the assistant use the compressed air targeting suspected leaking area. If there is leakage, air bubbles will appear. 1.11.1.2 Maintenance guidance Water leaking repair for body Depending on the position of water leakage, certain components may need to be dismantled. 1. From the inside or outside the vehicle slit open the seam adhesive. 2. Clean and remove all the old adhesive residues from the leaking area. 3. Apply body and joint sealant on the cleaned area. 4. Wait for several hours so that the sealant is fully cured. 5. Inspect whether there are water leakage. 6. Install previous dismantle component. Fixed water leakage repair for window Depending on the position of water leakage, certain components may need to be dismantled. 1. Determine the specific position of water leakage . 2. If the front windshield edge water leakage use a dedicated seam adhesive to repair or replace the windshield. 3. If it is fixed windows side-water leakage, use a dedicated seam adhesive to repair or replace the windshield. 79 |
