Ford F150 Pickup. Instruction - part 256

Fig. 362: Attaching Backrest J-Clip
Courtesy of FORD MOTOR CO.

11. Install the front and the outer safety belt web guides.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 363: Installing Front And Outer Safety Belt Web Guides
Courtesy of FORD MOTOR CO.

NOTE:

Note the retainer bracket orientation. Do not reverse the bracket during
reassembly.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 364: Installing Retainer Bracket And Secure With Two Screws
Courtesy of FORD MOTOR CO.

12. Install the retainer bracket and secure with two screws.

NOTE:

The LH and RH tower cap covers are not interchangeable.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 365: Installing Four Tower Cap Attachment Screws And LH, RH And Front Screw Covers
Courtesy of FORD MOTOR CO.

13. Install the four tower cap attachment screws and the LH, RH and front screw covers.

NOTE:

The LH and RH head restraint rod guides are not interchangeable.

NOTE:

Install new units during reassembly. The LH and RH head restraint rod
guides will be damaged during removal.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup
