7. With all the restraint system diagnostic tools removed, prove out the supplemental restraint system (SRS).

Refer to SYSTEM OPERATION CHECK .

REAR SEAT BACKREST - SUPERCREW 60 PERCENT

Removal and Installation

1. Remove the screws.

Fig. 165: Removing Screws
Courtesy of FORD MOTOR CO.

2. Remove the access covers then remove the screws.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 166: Removing Access Covers And Screws
Courtesy of FORD MOTOR CO.

3. Fold the seat, then unclip the J-clip.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 167: Folding Seat, Then Unclip J-Clip
Courtesy of FORD MOTOR CO.

4. Remove the staples.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 168: Removing Staples
Courtesy of FORD MOTOR CO.

5. Unclip the seat backrest.

z

Pull upward and insert the upholstery clip into the seat backrest.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup
