Fig. 63: Removing Speedometer Drive Gear Or OSS Tone Ring
Courtesy of FORD MOTOR CO.

7. Slide the first/second and third/forth synchronizer sleeves forward to lock the transmission into first

and third gears.



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup



Fig. 64: Sliding First/Second & Third/Forth Synchronizer Sleeves
Courtesy of FORD MOTOR CO.

NOTE:

Release the stake mark on the nut.



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup



Fig. 65: Removing Countershaft Locknut
Courtesy of FORD MOTOR CO.

8. Remove and discard the countershaft locknut.

9. Remove the countershaft rear bearing and the countershaft rear bearing thrust washer.



2003 Ford Pickup F150

2003 TRANSMISSIONS Instruction Transmission - F150 Pickup



Fig. 66: Removing Countershaft Rear Bearing & Thrust Washer
Courtesy of FORD MOTOR CO.

NOTE:

Release the stake mark on the nut.
