1. Remove the steering column (3C529). For additional information, refer to COLUMN .

Fig. 148: Removing Bearing Retainer
Courtesy of FORD MOTOR CO.

2. Remove the bearing retainer (3C610).

3. Remove the steering column lock housing bearing (3E700).

WARNING:

To reduce the risk of serious personal injury, read and follow all
warnings, cautions, notes and instructions in the steering column
removal and installation procedure.

CAUTION: Carefully note the position of the steering column lock gear, bearing

and retainer prior to removal.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



Fig. 149: Removing Steering Column Lock Housing Bearing
Courtesy of FORD MOTOR CO.

4. Remove the steering column lock gear (3E717).



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



Fig. 150: Removing Steering Column Lock Gear
Courtesy of FORD MOTOR CO.

5. Remove the shock absorber electronic steering sensor (18B015).

1. Disconnect the electrical connector.

2. Remove the screws.

3. Remove the shock absorber electronic steering sensor.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



Fig. 151: Removing Shock Absorber Electronic Steering Sensor
Courtesy of FORD MOTOR CO.
