Fig. 71: Closing Safety Belt Guide Cover
Courtesy of FORD MOTOR CO.

38. Install the driver side safety belt guide.

1. Position the safety belt guide.

2. Install the nut.

3. Close the safety belt guide cover.

39. Remove the restraint system diagnostic tool from the passenger side safety belt retractor pretensioner

CAUTION: Inspect the shoulder safety belt guide cover for damage. If the

shoulder safety belt guide cover is damaged or if it does not
remain closed, install a new shoulder safety belt guide cover.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



electrical connector.

Fig. 72: Removing Restraint System Diagnostic Tool
Courtesy of FORD MOTOR CO.

40. Connect the passenger side safety belt retractor pretensioner electrical connector.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



Fig. 73: Connecting Passenger Side Safety Belt Retractor Pretensioner Electrical Connector
Courtesy of FORD MOTOR CO.

41. Position the safety belt through the passenger side lower corner trim panel.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



Fig. 74: Positioning Safety Belt Through Passenger Side Lower Corner Trim Panel
Courtesy of FORD MOTOR CO.

42. Position the passenger side lower corner trim panel and push in near the door jamb, seating the retaining

clips. Install the three pin-type retainers.
