Fig. 63: Installing Hood Latch
Courtesy of FORD MOTOR CO.

2. Close the hood to adjust the hood latch.

3. Adjust the hood latch and tighten the bolts.

If necessary, use Multi-Purpose Grease Spray F5AZ-19G209-AA or equivalent meeting Ford
specification ESR-M1C159-A to lubricate the latch.

2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup

Fig. 64: Adjusting Hood Latch
Courtesy of FORD MOTOR CO.

4. Install the radiator grille. Refer to RADIATOR GRILLE .

FRONT DOOR LATCH

Removal and Installation

1. Raise the front door window to the closed position.

2. Disconnect the battery ground cable.

3. Remove the front door trim panel. Refer to FRONT DOOR TRIM PANEL .

4. Position the watershield aside.

5. Remove the bolt and position the rear glass run channel aside.

2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup

Fig. 65: Removing Bolt And Positioning Rear Glass Run Channel Aside
Courtesy of FORD MOTOR CO.

6. Disconnect the actuating rods.

1. If equipped disconnect the actuating rod from the lock cylinder.

2. Release the locking clip.

3. Disconnect the exterior door handle actuating rod from the front door latch.

2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup

Fig. 66: Disconnecting Actuating Rods
Courtesy of FORD MOTOR CO.

7. Remove the screws and position the front door latch aside.

Discard the screws.
