13. (K24) CRANKSHAFT POSITION SENSOR SIGNAL CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (K24) CKP Sensor Is the resistance above 1000 ohms? Yes >> Go To 14 No >> Repair the (K24) CKP Sensor Signal circuit for a short to ground. Perform the ECM Verification Test Ver. 1. (Refer to 9 - 14. (K24) CRANKSHAFT POSITION SENSOR SIGNAL CIRCUIT SHORTED TO THE (K925) CKP SENSOR Measure the resistance between the (K24) CKP Sensor Signal circuit Is the resistance above 1000 ohms? Yes >> Replace and program the Engine Control Module in accor- dance with the Service Information. Perform the ECM Verification Test Ver. 1. (Refer to 9 - No >> Repair the (K24) CKP Sensor Signal circuit and the (K925) CKP Sensor Ground circuit for a short together. Perform the ECM Verification Test Ver. 1. (Refer to 9 - PM ENGINE ELECTRICAL DIAGNOSTICS - DIESEL 9 - 1091 |
