Fig. 47: Stabilizer Bar
Courtesy of CHRYSLER LLC

10. Remove the stabilizer link bolt (2) at the lower control arm. See REMOVAL.

Fig. 48: Upper Ball Joint Separation
Courtesy of CHRYSLER LLC

11. Remove the upper ball joint nut.

12. Separate the upper ball joint from the knuckle (3) using remover 9360 (2).



2007 Dodge Nitro R/T

2007 SUSPENSION Suspension - Nitro



Fig. 49: Identifying Steering Knuckle, Remover 9360, Shock Assembly & Knuckle
Courtesy of CHRYSLER LLC

13. Push downward on the steering knuckle (3) and support the knuckle (4) this will allow access to remove

the shock.

14. Remove the shock assembly (1) from the vehicle.

15. Remove the spring from the shock (if needed). See REMOVAL.

SHOCK - RIGHT SIDE

1. Remove the air box. Refer to REMOVAL for 3.7L - SERVICE INFORMATION or REMOVAL for

4.0L - SERVICE INFOMATION.

2. Remove the four upper shock mounting nuts.

3. Raise and support the vehicle.

4. Remove the right side tire assembly.

5. Remove the caliper and support. Refer to REMOVAL .



2007 Dodge Nitro R/T

2007 SUSPENSION Suspension - Nitro



Fig. 50: Clevis Bracket
Courtesy of CHRYSLER LLC

6. Remove the lower bolt (4) at the lower control arm securing the clevis bracket (3).

Fig. 51: Stabilizer Bar
Courtesy of CHRYSLER LLC

7. Remove the stabilizer link bolt (2) at the lower control arm. See REMOVAL.

Fig. 52: Upper Ball Joint Separation
Courtesy of CHRYSLER LLC

8. Remove the upper ball joint nut.

9. Separate the upper ball joint from the knuckle (3) using remover 9360 (2).



2007 Dodge Nitro R/T

2007 SUSPENSION Suspension - Nitro



Fig. 53: Identifying Steering Knuckle, Remover 9360, Shock Assembly & Knuckle
Courtesy of CHRYSLER LLC

10. Pull downward on the knuckle and support the knuckle (4) to allow access.

11. Remove the shock assembly (1) from the vehicle.

12. Remove the spring from the shock (if needed). See REMOVAL.

INSTALLATION

SHOCK - LEFT SIDE

Fig. 54: Identifying Steering Knuckle, Remover 9360, Shock Assembly & Knuckle
Courtesy of CHRYSLER LLC

1. Install the spring to the shock (if removed). See INSTALLATION.

2. Install the shock assembly (1) to the vehicle.

3. Install the four upper shock mounting nuts. Tighten the nuts to 108 N.m (80 ft.lbs.).
