Fig. 129: Transmission Mount & Crossmember
Courtesy of CHRYSLER LLC

5. Install transmission crossmember (2) and tighten bolts to 47 N.m (35 ft. lbs.). Install transmission mount

(1) bolts and tighten to 47 N.m (35 ft. lbs.).



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 130: Backup Lamp Switch & Wiring Connector
Courtesy of CHRYSLER LLC

6. Install backup lamp (2) wiring connector (1).



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 131: Identifying Clutch Slave Cylinder Nuts & Cylinder
Courtesy of CHRYSLER LLC

7. Install clutch slave cylinder (2) and mounting nuts (1).



2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro



Fig. 132: Identifying Transfer Case & Transmission
Courtesy of CHRYSLER LLC

8. Install transfer case (1) on transmission (2), if equipped.

9. Install propeller shaft/shafts with reference marks aligned.
