Fig. 93: Identifying Idler Gear & Bearing
Courtesy of CHRYSLER LLC

5. Install idler gear (1) bearing (2) into gear.

2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro

Fig. 94: Identifying Idler Gear & Thrust Washer
Courtesy of CHRYSLER LLC

6. Install idler gear (1) thrust washer (2) on idler gear.

2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro

Fig. 95: Identifying Idler Gear & Shaft Support
Courtesy of CHRYSLER LLC

7. Install idler gear (1) shaft support (2) into housing.

2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro

Fig. 96: Identifying Idler Gear, Shaft & Shaft Support Hole
Courtesy of CHRYSLER LLC

8. Install idler gear (1) shaft (2) with shaft bolt hole aligned with shaft support hole (3).

2007 Dodge Nitro R/T

2007 MANUAL TRANSMISSION NSG370 - Diagnosis & Overhaul - Nitro
