Fig. 364: Handle Assist
Courtesy of CHRYSLER LLC

1. Position the assist handle to the headliner and install the screws (2).

2. Close the covers (1) on either end of the assist handle.

HEADLINER

REMOVAL

HEADLINER

Fig. 365: Harness Clip, D-Pillar Body & Body Harness Connectors
Courtesy of CHRYSLER LLC

1. Disconnect the negative battery cable.

NOTE:

Inspect and replace the screw retaining clips if damaged.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



2. If equipped, remove the sunroof opening trim ring.

3. Remove the quarter trim, see REMOVAL.

4. Remove the upper B-pillar trim, see REMOVAL.

5. Remove the A-pillar trim, see REMOVAL.

6. If equipped, remove the overhead console, refer to REMOVAL .

7. Remove the sun visor support, see REMOVAL.

8. Remove the visors, see REMOVAL.

9. Remove the assist handles, see REMOVAL.

10. Disconnect the body harness connectors (3).

11. Remove the harness clip (1) from the D-pillar body (2).

Fig. 366: Mirror Electrical Connector
Courtesy of CHRYSLER LLC

12. If equipped, disconnect the electrical connector (1) from the mirror (2).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 367: Dual Lock Areas, Sunroof, Spacer Foam Blocker, Headliner & Sunroof Motor Jumper
Courtesy of CHRYSLER LLC

13. Disconnect the sunroof motor jumper (5).

14. Using a trim stick C-4755 or equivalent, separate the duel lock fasteners (1) of the headliner (4) to

remove the headliner from the sunroof (2).

Fig. 368: Lift Gate Washer Hose
Courtesy of CHRYSLER LLC

15. Cut the lift gate washer hose (1) at the A-pillar.

Fig. 369: DVD Electrical Connector
Courtesy of CHRYSLER LLC

16. Remove the harness clip (2) from the D-pillar body (1).

17. Disconnect the DVD electrical connectors (3).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 370: Satellite Radio Body Antenna Connector, Power Connector & Radio Body Antenna
Connector
Courtesy of CHRYSLER LLC

18. If equipped, disconnect the satellite radio body antenna connector (1).

19. Disconnect the power connector (2).

20. Disconnect the radio body antenna connector (3).

Fig. 371: Radio/Satellite Connections L/F
Courtesy of CHRYSLER LLC

21. Disconnect the radio and/or satellite electrical connectors along the left A-pillar.
