FENDER - FRONT

REMOVAL

FENDER - FRONT

Fig. 229: Removing/Installing Fascia Assembly
Courtesy of CHRYSLER LLC

1. Remove the front fascia, refer to REMOVAL .

2. Remove the front fascia support bracket (1).

3. Remove the grille, see REMOVAL.

1 - Fascia Support Bracket
2 - Fastener
3 - Carrier
4 - Fog Lamp Connectors
5 - Fascia
6 - Push Pins
7 - Rivet



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 230: Screws, Fender & Applique
Courtesy of CHRYSLER LLC

4. Remove the two screws (1) from the fender applique (3).

5. Use a trim stick C-4755 or equivalent, separate the fender applique (3) from the fender (2).

6. Remove the front wheel opening flare molding, see REMOVAL.

Fig. 231: Removing/Installing Fender
Courtesy of CHRYSLER LLC

7. Remove the bolts and remove the fender.

INSTALLATION

FENDER - FRONT



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 232: Removing/Installing Fender
Courtesy of CHRYSLER LLC

1. Align the fender with adjacent body parts, install and tighten bolt (2) first then tighten bolt (1) then all

remaining bolts (3). Tighten all bolts to 9 N.m (80 in. lbs.). Make sure there are no excessive gaps
between the fender and the door assemblies, see SPECIFICATIONS.

2. Install the front wheel opening flare molding, see INSTALLATION.

Fig. 233: Screws, Fender & Applique
Courtesy of CHRYSLER LLC

3. Align the fender applique (3) to the fender assembly (2) and apply enough hand pressure in order to make

sure the clips are fully seated.

4. Install the two screws (1) to the fender applique (3).

5. Install the grille, see INSTALLATION.

NOTE:

Follow the mandatory torque sequence when tightening the fender bolts.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 234: Removing/Installing Fascia Assembly
Courtesy of CHRYSLER LLC

6. Install the fender support bracket (1).

7. Install the fascia assembly, refer to INSTALLATION .

GLASS - OUTSIDE REARVIEW MIRROR

REMOVAL

GLASS - OUTSIDE REARVIEW MIRROR

1. Carefully pull/pry the broken glass holder from the mirror assembly.

2. Disconnect the heated mirror electrical connectors from the terminals on the mirror glass holder, if

equipped.

INSTALLATION

GLASS - OUTSIDE REARVIEW MIRROR

1 - Fascia Support Bracket
2 - Fastener
3 - Carrier
4 - Fog Lamp Connectors
5 - Fascia
6 - Push Pins
7 - Rivet

WARNING:

Always wear eye and hand protection when servicing the mirror
assembly. Failure to observe these warnings may result in personal injury
from broken glass.
