Dodge Nitro. Manual - part 400

Fig. 152: Removing/Installing Interior Handle Lock Rod And Grommet
Courtesy of CHRYSLER LLC

14. Install the interior handle lock rod into the carrier and seat the grommet.

Fig. 153: Carrier & Interior Handle
Courtesy of CHRYSLER LLC

15. Install the interior lock rod to the interior handle (2). Make sure the lock rod is positioned properly to the

carrier (1).

NOTE:

All the lock rods are color coded to help identify the location for the
particular lock rod.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 154: Disconnecting/Connecting Interior Handle Lock Rod
Courtesy of CHRYSLER LLC

16. Connect the interior handle lock rod to the latch.

Fig. 155: Inside Lock Rod, Grommet & Carrier Plate
Courtesy of CHRYSLER LLC

17. Install the inside lock rod (1) to the carrier plate (3) and seat the grommet (2).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 156: Disconnecting/Installing Inside Lock Rod
Courtesy of CHRYSLER LLC

18. Connect the inside lock rod to the latch.

Fig. 157: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

19. Install the carrier plate (2) to the door (4).

20. Install the electrical connector (1) to the door (4) and connect the electrical connector.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 158: Removing/Installing Rear Door Latch Screws
Courtesy of CHRYSLER LLC

21. Install the screws securing the door latch to the door shut face and tighten screws to 7 N.m (60 in. lbs.).

22. Install the 9 screws to the carrier plate and tighten screws to 5.5 N.m (50 in. lbs.).

Fig. 159: Disconnecting/Connecting Door Harness Electrical Connector From/To Body Connector
Courtesy of CHRYSLER LLC

23. Connect the door harness electrical connector (1) to the body connector (2) at the B-pillar.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro
