Dodge Nitro. Manual - part 397

Courtesy of CHRYSLER LLC

2. Remove the trim panel from the door. See REMOVAL.

Fig. 128: Removing/Installing Door Plug & Rear Exterior Handle Nut
Courtesy of CHRYSLER LLC

3. Remove the door plug (2).

4. Remove rear exterior handle nut (1).

Fig. 129: Door Glass & Window Regulator
Courtesy of CHRYSLER LLC

5. Access the window regulator through the hole in the carrier plate. Disconnect the window regulator (2)

from the door glass (1) and support the glass.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 130: Removing/Installing Rear Door Latch Screws
Courtesy of CHRYSLER LLC

6. Remove the three screws securing the door latch to the door shut face.

Fig. 131: Disconnecting/Connecting Door Harness Electrical Connector From/To Body Connector
Courtesy of CHRYSLER LLC

7. Disconnect the door harness electrical connector (1) from the body connector (2) at the B-pillar.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 132: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

8. Remove the 9 screws (3) from the carrier plate (2).

9. Remove the electrical connector (1) from the door (4).

10. Remove the carrier plate (2) from the door (4).

Fig. 133: Disconnecting/Installing Inside Lock Rod
Courtesy of CHRYSLER LLC

11. Disconnect the inside lock rod from the latch.

NOTE:

The window regulator is not serviceable. The new carrier plate will come
equipped with the regulator assembly installed.

NOTE:

All the lock rods are color coded to help identify the location for the
particular lock rod.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 134: Inside Lock Rod, Grommet & Carrier Plate
Courtesy of CHRYSLER LLC

12. Disengage the grommet (2) and remove the inside lock rod (1) from carrier plate (3).

Fig. 135: Disconnecting/Connecting Interior Handle Lock Rod
Courtesy of CHRYSLER LLC

13. Disconnect the interior handle lock rod from the latch.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro
