11. Using Special Tool 8511 (1), remove crankshaft front seal. INSTALLATION CAUTION: To prevent severe damage to the Crank- 1. Using Special Tool 8348 and 8512 (2,3), install crankshaft front seal. 2. Install vibration damper (Refer to 9 - ENGINE/EN- GINE BLOCK/VIBRATION DAMPER - INSTALLA- 3. Install radiator cooling fan and shroud (Refer to 7 - COOLING/ENGINE/RADIATOR FAN - INSTALLA- 4. Install upper radiator hose. 5. Install A/C compressor and tighten fasteners to 54 N·m (40 ft. lbs.). 6. Install accessory drive belt refer (Refer to 7 - COOLING/ACCESSORY DRIVE/DRIVE BELTS - 7. Refill cooling system (Refer to 7 - COOLING - STANDARD PROCEDURE). 8. Connect negative cable to battery. SEAL - CRANKSHAFT OIL - REAR DIAGNOSIS AND TESTING - REAR SEAL AREA LEAKS Since it is sometimes difficult to determine the source of an oil leak in the rear seal area of the engine, a more If the leakage occurs at the crankshaft rear oil seal area: 9 - 958 ENGINE - 4.7L SERVICE INFORMATION ND |
