For complete circuit diagrams, refer to the appropriate wiring information. The wiring information includes wir-
ing diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector
pin-out information and location views for the various wire harness connectors, splices and grounds.

The power distribution system also incorporates various types of circuit control and protection features, including:

•

Automatic resetting circuit breakers

•

Blade-type fuses

•

Cartridge fuses

•

Relays

OPERATION

The power distribution system for this vehicle is designed to provide safe, reliable, and centralized distribution points
for the electrical current required to operate all of the many standard and optional factory-installed electrical and
electronic powertrain, chassis, safety, security, comfort and convenience systems. At the same time, the power dis-
tribution system was designed to provide ready access to these electrical distribution points for the technician to use
when conducting diagnosis and repair of inoperative circuits. The power distribution system can also prove useful
for the sourcing of additional electrical circuits that may be required to provide the electrical current needed to oper-
ate many accessories that the vehicle owner may choose to have installed.

8W-97 POWER DISTRIBUTION - SERVICE INFORMATION

8W - 97 - 1
