MECHANICAL DIAGNOSIS (KEY DIFFICULT TO ROTATE) (Refer to 19 - STEERING/COLUMN/IGNITION SWITCH - DIAGNOSIS AND TESTING). CYLINDER-KEY/LOCK REMOVAL The ignition key (1) must be in the key cylinder (2) for 1. Disconnect negative cable from battery. 2. Remove upper and lower covers (shrouds) from steering column. 3. Place shifter in PARK position. 4. A retaining pin is located at side of key cylinder assembly (2). a. Rotate key to RUN position. b. Press in on retaining pin while pulling key cyl- inder (1) from ignition switch. 8I - 26 IGNITION SYSTEM - SERVICE INFORMATION ND |
