15. Install the upper B-pillar trim panels, (Refer to 23 - BODY/INTERIOR/PANEL-B PILLAR UPPER TRIM - INSTALLATION). 16. Seat the top of each of door seal to the door opening. MIRROR-INSIDE REARVIEW REMOVAL 1. If equipped, disconnect the headliner wire harness connector from the mirror base (1). 2. Loosen the mirror base set screw. 3. Slide the mirror base upward and off of the support bracket (2). 23 - 228 INTERIOR ND |
