P0720-OUTPUT SPEED SENSOR CIRCUIT (CONTINUED) 5. (T14) OUTPUT SPEED SENSOR SIGNAL CIRCUIT SHORT TO GROUND Measure the resistance between ground and the (T14) Output Speed Is the resistance below 5.0 ohms? Yes >> Repair the (T14) Output Speed Sensor Signal circuit for a short to ground. Perform 45RFE/545RFE TRANSMISSION VERIFICATION No >> Go To 6 6. (T13) SPEED SENSOR GROUND CIRCUIT SHORT TO GROUND Measure the resistance between ground and the (T13) Speed Sensor Is the resistance below 5.0 ohms? Yes >> Repair the (T13) Speed Sensor Ground circuit for a short to ground. Perform 45RFE/545RFE TRANSMISSION VERIFICATION No >> Go To 7 21 - 464 AUTOMATIC TRANSMISSION 545RFE - ELECTRICAL DIAGNOSTICS ND |
