C1008–BRAKE FLUID LEVEL INPUT CIRCUIT HIGH (340) (CONTINUED) 5. ANTI-LOCK BRAKE MODULE Turn the ignition off. Inspect the related wiring harness. Look for any chafed, pierced, pinched, or partially broken wires. Inspect the related wire harness connectors. Look for broken, bent, pushed out, or corroded terminals. Refer to any Technical Service Bulletins that may apply. Were any problems found? Yes >> Repair as necessary. Perform ABS VERIFICATION TEST - VER 1. (Refer to 5 - BRAKES/ELECTRICAL - DIAGNOSIS AND No >> If no other problems are found, replace the Anti-lock Brake Module in accordance with the Service Infor- mation. Perform ABS VERIFICATION TEST - VER 1. (Refer to 5 - BRAKES/ELECTRICAL - DIAGNOSIS AND 6. WIRING HARNESS INSPECTION Turn the ignition off. Inspect the related wiring harness. Look for any chafed, pierced, pinched, or partially broken wires. Inspect the related wire harness connectors. Look for broken, bent, pushed out, or corroded terminals. Refer to any Technical Service Bulletins that may apply. Were any problems found? Yes >> Repair as necessary. Perform ABS VERIFICATION TEST - VER 1. (Refer to 5 - BRAKES/ELECTRICAL - DIAGNOSIS AND No >> Test Complete. 5 - 130 BRAKES - ABS ELECTRICAL DIAGNOSTICS ND |
