(4) Disconnect electrical connector and vacuum hose. (5) Pull cable away from servo to expose retaining clip and remove clip attaching cable to servo. INSTALLATION (1) With throttle in full open position align hole in vehicle speed control cable sleeve with hole in servo (2) Connect vacuum hose to servo. attaching bracket and tighten to 12 N Im (105 in. lbs.) torque. (5) Insert servo studs through holes in vehicle speed control cable and mounting bracket. (6) Install nuts, tighten to 7 N Im (60 in. lbs.) torque. VEHICLE SPEED CONTROL SWITCH REMOVAL The vehicle speed control switch is mounted in the steering wheel and wired through the clock spring WARNING: IF REMOVAL OF AIR BAG MODULE IS REMOVAL (1) Turn off ignition. wheel. (3) Rock switch away from air bag or horn pad while lifting switch out of steering wheel. (4) Disconnect 4-way electrical connector. INSTALLATION (1) Turn off ignition. spring to switch. (3) Place switch in steering wheel, sliding the for- ward edge of switch under air bag or horn pad. Line (4) Attach switch to wheel with two screws start- ing with the screw at the left end of the switch. 8H - 10 VEHICLE SPEED CONTROL Ä |
