DAF LF45, LF55 Series. Manual - part 686

©

 200419

89

GEARBOX



3

3

0535932

Ring holder for mounting input shaft axial ring

0694720

Gripper for demounting auxiliary shaft tapered roller

bearing on output side (i.c.w. 0535662)

0694770

M12 lifting eye for demounting/mounting intermediate

shaft/auxiliary gearbox housing

0694771

Gripper for demounting auxiliary shaft bearing (i.c.w.

0535662)

0535932

0694720

0694770

0694771

GEARBOX

90

©

 200419

3

3

0694779

Hoisting tool for mounting/demounting selector shaft
and auxiliary shaft (i.c.w. 12400410/1240414/1240413)

0694780

Output shaft oil seal installer (i.c.w. 1310466)

0694793

Gripper for demounting secondary shaft bearing (i.c.w.
0535662)

0694796

Gripper for demounting auxiliary shaft tapered roller
bearing (i.c.w. 0192548/0535793/0535662)

0694779

0694780

0694793

0694796

©

 200419

91

GEARBOX



3

3

0694798

Lifting eye for demounting/mounting main shaft

0694814

Gripper for demounting intermediate shaft tapered roller

bearing (i.c.w. 0535662)

0694815

Gripper for demounting intermediate shaft tapered roller

bearing

0694816

Installer for oil seal (60 x 74), output shaft

0694798

1x56 137 200

0694814

0694815

0694816

GEARBOX

92

©

 200419

3

3

0694817

Protective sleeve for mounting oil seal and selector
shaft scraper ring

0694818

Driving tool for removing and fitting selector housing
bearing

0694819

Lifting plate, auxiliary and main shafts

0694858

Adapter, oil pump drive cam puller (i.c.w. 0535662)

0694817

0694818

0694819

0694858
