3-9

Inspection and adjustment

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΛΦ45/55 series

5

3.

Check/correct the valve clearance of the

specified inlet and exhaust valves. Set the

correct valve clearance by loosening the

locknut and rotating the adjusting screw in

the correct direction; see "Technical data" for

the correct valve clearance.

4.

Using an open-end spanner on the fan shaft,

turn the crankshaft one rotation further so

that the mark (A) is once again between the

bolts (B) and the valves of cylinder 6 overlap.

5.

Check/correct the valve clearance of the

specified inlet and exhaust valves. Set the

correct valve clearance by loosening the

locknut and rotating the adjusting screw in

the correct direction; see "Technical data" for

the correct valve clearance.

6.

Fit the valve cover. See "Removal and

installation".

M201064

Cylinder

Inlet valve

Exhaust valve

1

2

X

3

X

4

X

5

X

6

X

X

M201065

A

B

B

Cylinder

Inlet valve

Exhaust valve

1

X

X

2

X

3

X

4

X

5

X

6

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

3-10

©

 200515

Inspection and adjustment

5

ΛΦ45/55 series

3.11 CHECKING THE POLY-V-BELT

1.

Check the poly-V-belt for damage and signs

of serious wear.

3.12 CHECKING THE COOLANT FREEZING POINT

When the coolant is hot, there is an

overpressure in the cooling system.

Carefully remove the filler cap to

release the overpressure.

Do not remove the filler cap when the

engine is running.

Coolant is a toxic fluid. Contact with

the skin should therefore be

avoided.

In the event of contact with the skin:

remove with paper or a cloth, wash

with soap and water. If irritation

persists, consult a doctor.

If swallowed: DO NOT induce

vomiting. Rinse mouth, drink two

glasses of water and consult a

doctor.

In the event of inhalation: get some

fresh air and rest.

In order to avoid damaging the

cylinder block, do not top up a warm

engine with coolant.

1.

Check the anti-freeze content of the coolant.

Fill the cooling system with anti-freeze, if this

has not been done yet. Always use only

coolants that meet DAF specifications.

2.

Consult the manufacturer’s instructions for

the correct anti-freeze mixing ratio.

Preferably, use 40% anti-freeze on an

ethylene glycol base. At this percentage, not

only good frost protection, but also good

corrosion protection is guaranteed.

}

%

O

o

M2016

C

100

0

90

10

80

20

70

30

60

40

50

50

40

60

30

70

20

80

10

90

-80

-70

-60

-50

-40

-30

-20

0

-10

0

100

2

H

Ethyleenglycol

©

 200515

3-11

Inspection and adjustment

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΛΦ45/55 series

5

3.13 CHECKING FOR FUEL LEAKS

1.

Visually inspect all hose connections and

fuel system components for leaks.

3.14 CHECKING THE COMPONENTS AND HOSE CONNECTIONS FOR LEAKS

1.

Check all hose connections and cooling

system components for leaks.

2.

Check the hose connections and inlet

system components.

3.15 CHECKING THE EXHAUST SYSTEM

1.

Visually inspect the exhaust system for

leaks.

2.

Check the exhaust suspension points.

3.

Check that no heat transfer (due to

accumulated dirt, for example) can take

place to the exhaust system area, such as

pipes, components etc.

3.16 CHECKING THE RADIATOR AND INTERCOOLER FOR FOULING

1.

Visually inspect the radiator and intercooler

for fouling If necessary, clean the radiator

and intercooler, see "Cleaning".

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

3-12

©

 200515

Inspection and adjustment

5

ΛΦ45/55 series

3.17 CHECK THE AIR INLET DUST TRAPPING VALVE

1.

Check the rubber sealing valve (1) at the

bottom of the filter housing for clogging and

damage.

Steering gear and brake system

3.18 CHECKING THE STEERING BALL JOINT SLEEVE FOR DAMAGE

Inspection, locking devices and dust cover
1.

Check that the steering ball joint dust cover

or seal is not damaged. Replace the steering

ball joint if damaged.

2.

If a castle nut is fitted, check that the locking

devices are present and undamaged.

I4 00 535

3

1

2

S7 00 592
