DAF LF45, LF55 Series. Manual - part 639

©

 200515

1-1

Maintenance intervals

MAINTENANCE SCHEDULE

ΛΦ45/55 series

4

1. MAINTENANCE INTERVALS

1.1 MAINTENANCE SCHEDULE

The service intervals stated in the maintenance

schedule are based on use of the oils and fuels

specified by DAF.

1.

Automatic gearboxes are subject to different

changing intervals; see maintenance

schedule notes. Extended changing interval

not permitted for ZF 6S-850 gearbox.

2.

Changing interval for 1132 rear axle

450,000 km max.

+

+

Maintenance

schedule

LF45
LF55

1x per YEAR

G000318

 X service

 Y service

40.000 km

40.000 km

40.000 km

1 year

max. 100.000 km

1 year

max. 100.000 km

1 year

max. 150.000 km

3 year

max. 180.000 km

3 year

max. 300.000 km

3 year

max. 450.000 km

1 year

max. 100.000 km

1 year

max. 100.000 km

1 year

max. 150.000 km

2 year

max. 120.000 km

3 year

max. 300.000 km

3 year

max. 300.000 km

Ext.

Ext.

Ext.

(1)

(2)

MAINTENANCE SCHEDULE

1-2

©

 200515

Maintenance intervals

4

ΛΦ45/55 series

1.2 EXPLANATORY NOTES ON THE MAINTENANCE SCHEDULE

Maintenance group classification
Depending on the use to which the vehicle is put,

the vehicle is placed in maintenance group

I, II or III.

Maintenance group I
Operation on building sites, in quarries, etc.

-

Operation on unmetalled roads

-

Traffic in dusty conditions

-

Sanitation department vehicles

-

Distribution transport with an annual mileage

of up to 30,000 km.

Maintenance group II
Urban and regional transport

-

Distribution traffic in urban areas

-

Traffic between adjacent villages/cities

Maintenance group III
(Inter)national traffic

-

Long-distance/very long-distance traffic

Standard changing interval
This is the standard changing interval symbol.

See the "Fluids and lubricants" specifications

manual for the prescribed oil specification.

Extended changing interval
This is the extended changing interval symbol.

If the prescribed oil specification and any

additional conditions (see specification manual

"Fluids and lubricants") are complied with, an

extended changing interval may be applied.

G0  00 230

Ext.

G0  00 229

©

 200515

1-3

Maintenance intervals

MAINTENANCE SCHEDULE

ΛΦ45/55 series

4

X service
This is the symbol for an X service.

An X service is a mileage-dependent

maintenance check which consists of changing

the engine oil plus a number of visual inspections.

Note:

An X service must be carried out at least once a

year.

Y service
This is the symbol for a Y service.

A Y service is an annual maintenance check

consisting of several maintenance activities plus

changing of the gearbox and rear axle oil.

Note:

If the prescribed oil specification (see

specification manual "Fluids and lubricants") is

complied with, an extended changing interval

may be applied.

Automatic gearboxes are subject to different

changing intervals.

G000086

+

 X service

G000087

+

1x per YEAR

 Y service

(1)

Automatic Allison gearbox

Maintenance group I

Standard changing interval 1 year/maximum

40,000 km

Extended changing interval 3 years/maximum

80,000 km

Maintenance group II

Standard changing interval 1 year/maximum

40,000 km

Extended changing interval 3 years/maximum

160,000 km

Maintenance group III

Standard changing interval 1 year/maximum

40,000 km

Extended changing interval 3 years/maximum

160,000 km

MAINTENANCE SCHEDULE

1-4

©

 200515

Maintenance intervals

4

ΛΦ45/55 series

1.3 EFFECT OF DIESEL FUEL AND PTO HOURS ON MAINTENANCE INTERVALS

Diesel fuels

PTO hours
PTO hours should be converted into mileage

according to the following formula:

1 PTO hour = 40 km

1.4 MAINTENANCE IN SPECIAL OPERATING CONDITIONS

Contact a DAF dealer/main branch or importer for

vehicles used in very specific or heavy

conditions.

The service intervals can be modified, if

necessary, in consultation with the dealer/main

branch or importer to fit the appropriate operating

conditions.

1.5 FIRST SERVICE INSPECTION

The first service inspection should be carried out

between the first 7,500 and 10,000 km or at most

8 weeks after delivery of the vehicle, whichever

comes first.

Sulphur content

Engine oil change interval

> 0,2%

Halve interval to max. of 25,000 km
