© 200505 4-27 Removing and installing CE ENGINE ΛΦ45/55 series 2 5 4.19 REMOVAL AND INSTALLATION, CRANKSHAFT SENSOR RING Removing the crankshaft sensor ring Remove the attachment bolts from the viscous fan clutch and place the fan in the wind tunnel. 2. Remove the poly-V-belt. 3. Remove the attachment bolts from the vibration damper. 4. Remove the vibration damper and the crankshaft sensor ring. Installing the crankshaft sensor ring Fit the crankshaft sensor ring with vibration damper and tighten the attachment bolts to the specified torque. See "Technical data". Note: There is only one way of fitting the crankshaft sensor ring. For this purpose, a pin has been fitted which fits into a bore in the crankshaft sensor ring. 2. Fit the poly-V-belt. 3. Fit the fan and tighten the attachment bolts to the specified torque. See "Technical data". |
