DAF 95XF. Manual - part 672

DIFFERENTIAL GEAR

206

©

 200419

8

8

1310444

Differential bearing driving tool

1310446

Pinion seal driving tool

1310447

Pinion bearing driving tool

1310448

Pilot bearing pinion driving tool

1310444

1310446

1310447

1310448

©

 200419

207

DIFFERENTIAL GEAR



8

8

1310453

Rear axle hub oil seal driving tool

1310472

Guide sleeve (part of 1310475)

1310473

Driving tool (part of 1310475)

1310474

Pressure sleeve (part of 1310475)

1310453

1310472

1310473

1310474

DIFFERENTIAL GEAR

208

©

 200419

8

8

1310475

Mounting tool for trailing axle lifting device hydraulic
cylinder sealing ring

1329447

Lock bolt for differential lock

1329451

Shoulder bearing puller adapter (i.c.w. 0484820)
(supersedes 0484826)

1329465

Guide sleeve for disassembly/assembly of rear axle hub
LF class 3

1310475

1329447

1329451

1329465

©

 200419

209

DIFFERENTIAL GEAR



8

8

1329466

Hub nut wrench for rear axle, width across flats 105

1329490

Rear axle guide sleeve (10 tonnes)

1329493

Torx T70 for removing/fitting hub drain plug i.c.w.

lightweight metal rims

1329497

Disassembly and assembly tools for FTP hub seal

1329466

1329490

1329493

1329497
