DAF 95XF. Manual - part 649

GEARBOX

114

©

 200419

3

3

1453125

Assembly tool for selector shaft seal

1453138

Tool for fitting gearbox modulator

1453143

Gearbox control adjustment jig

1453145

Seal driving tool

V300893

V300894

V300900

RHD

LHD

V300896

©

 200419

115

GEARBOX



3

3

1453148

Installing output shaft seal

1453154

Spacer ring for fitting output shaft seal

V300897

V300898

GEARBOX

116

©

 200419

3

3

©

 200419

117

FUEL SYSTEM



4

4

USE OF TABLE OF CONTENTS

At the beginning of every group there is a table of contents containing the following columns:

-

DAF code number of the special tool

-

relevant vehicle series

-

relevant main components or systems

-

page number of the figure

If a tool is used for a main component, system or vehicle series, this is indicated by a code in the
column (1-2-3-R).
This code has the following meaning:
1 - tool for carrying out maintenance work and repair work resulting from it.
2 - tool for frequently recurring work.
3 - tool for less frequently recurring work.
R - replacement part of a tool.

Note:
If a special tool does not occur in the relevant section, look in group 0 (General).
The special tool in question is then one that occurs in several groups.
