DAF 95XF. Manual - part 642

GEARBOX

86

©

 200419

3

3

0535409

Input shaft seal driving tool

0535410

Odometer connecting piece seal driving tool

0535423

Gearbox front cover seal driving tool

0535659

Selector shaft seal and dust seal driving tool

0535409

0535410

0535423

0535659

©

 200419

87

GEARBOX



3

3

0535662

Puller, basic tool (i.c.w. various extensions/adapters/

bearing grippers)

0535703

Gearbox front cover oil seal installer

0535788

Puller for removing bearing bush

0535790

Counter-puller (i.c.w. 0535817)

0535662

0535703

0535788

0535790

GEARBOX

88

©

 200419

3

3

0535793

Extension for M65x2 (i.c.w. 0535662)

0535817

Puller for removing gearbox housing ball joint cover
(i.c.w. 0535790)

0535898

Output shaft seal driving tool

0535928

Driving tool for fitting lock plate on output shaft flange
bolts

0535793

0535817

0535898

0535928

©

 200419

89

GEARBOX



3

3

0535932

Ring holder for mounting input shaft axial ring

0694720

Gripper for demounting auxiliary shaft tapered roller

bearing on output side (i.c.w. 0535662)

0694770

M12 lifting eye for demounting/mounting intermediate

shaft/auxiliary gearbox housing

0694771

Gripper for demounting auxiliary shaft bearing (i.c.w.

0535662)

0535932

0694720

0694770

0694771
