XE ENGINE BRAKE

Safety instructions

95

XF series

1-2

7

©

 0008

4

95

XF series

General

XE ENGINE BRAKE

2-1

2.  GENERAL

2.1

LOCATION OF DEB COMPONENTS

i 400389

1

2

1.

DEB housing, cylinders 1 - 2 - 3

2.

DEB housing, cylinders 4 - 5 - 6

7

©

 0008

4

XE ENGINE BRAKE

General

95

XF series

2-2

2.2

OVERVIEW DRAWING DEB

1

2

4

5

3

6

i 400167

1.

Magnetic valve

2.

Control valve

3.

Operating piston

4.

Main piston

5.

Spring plate

6.

Set screw

7

©

 0008

4

95

XF series

General

XE ENGINE BRAKE

2-3

2.3

LOCATION OF EXHAUST BRAKE COMPONENTS

i 400388

3

2

4

1

1.

Butterfly valve operating cylinder

2.

Engine stop valve

3.

Supply pressure

4.

Butterfly valve housing

7

©
