FASTENER USAGE
DESCRIPTION
FASTENER USAGE
WARNING: USE OF AN INCORRECT FASTENER
MAY RESULT IN COMPONENT DAMAGE OR PER-
SONAL INJURY.
Fasteners and torque specifications references in
this Service Manual are identified in metric and SAE
format.
During any maintenance or repair procedures, it is
important to salvage all fasteners (nuts, bolts, etc.)
for reassembly. If the fastener is not salvageable, a
fastener of equivalent specification must be used.
THREADED HOLE REPAIR
Most stripped threaded holes can be repaired using
a Helicoil
t. Follow the vehicle or Helicoilt recommen-
dations for application and repair procedures.
INTERNATIONAL SYMBOLS
DESCRIPTION
The graphic symbols illustrated in the following
International Control and Display Symbols Chart are
used to identify various instrument controls. The
symbols correspond to the controls and displays that
are located on the instrument panel.
METRIC SYSTEM
DESCRIPTION
The metric system is based on quantities of one,
ten, one hundred, one thousand and one million.
The following chart will assist in converting metric
units to equivalent English and SAE units, or vise
versa.
INTERNATIONAL CONTROL AND DISPLAY SYMBOLS
1
High Beam
13
Rear Window Washer
2
Fog Lamps
14
Fuel
3
Headlamp, Parking Lamps, Panel Lamps
15
Engine Coolant Temperature
4
Turn Warning
16
Battery Charging Condition
5
Hazard Warning
17
Engine Oil
6
Windshield Washer
18
Seat Belt
7
Windshield Wiper
19
Brake Failure
8
Windshield Wiper and Washer
20
Parking Brake
9
Wind screen Demisting and Defrosting
21
Front Hood
10
Ventilating Fan
22
Rear hood (Decklid)
11
Rear Window Defogger
23
Horn
12
Rear Window Wiper
24
Lighter
