(9) Install ring gear-to-case bolts, with pinion shaft retainers (Fig. 196), and torque bolts to 95 N·m (70 (10) Using Miller Special Tool L-4410, and C-4171, install differential bearing to differential (extension (11) Using Miller Special Tool 5052 and C-4171, install differential bearing to differential (bearing (12) Using Miller Special Tool 6061 and C-4171, install differential bearing race to bearing retainer (13) Using Miller Special Tool L–4520 and C-4171, install differential bearing to extension housing. NOTE: Use Mopar T Silicone Rubber Adhesive Seal- ant, or equivalent, on retainer and extension hous- (14) Install differential assembly into transaxle case. Install differential bearing retainer (Fig. 199)and torque retainer-to-case bolts (Fig. 200)to 28 Fig. 195 Ring Gear Installation 1 - DIFFERENTIAL CASE Fig. 196 Ring Gear-to-Case Bolts 1 - DIFFERENTIAL CASE Fig. 197 Position Bearing Cone Onto Differential— Typical 1 - DIFFERENTIAL ASSEMBLY Fig. 198 Differential Bearing Retainer 1 - DIFFERENTIAL BEARING CUP RS 41TE AUTOMATIC TRANSAXLE 21 - 349 FINAL DRIVE (Continued) |
