(65) Install oil filter and new o-ring (Fig. 155). (66) Apply an 1/8” bead of Mopar t ATF RTV (MS- GF41) to oil pan and immediately install to case (Fig. (67) Install oil pan-to-case bolts and torque to 19 N·m (165 in. lbs.). (68) Install solenoid/pressure switch assembly and gasket to case (Fig. 157). (69) Install and tighten solenoid/pressure switch assembly-to-transaxle case bolts to 12 N·m (110 in. (70) Install and torque input and output speed sensors to case to 27 N·m (20 ft. lbs.). Fig. 154 Install Valve Body-to-Case Bolts 1 - VALVE BODY ATTACHING BOLTS (18) Fig. 155 Install Oil Filter and O-Ring 1 - OIL FILTER Fig. 156 Install Oil Pan 1 - OIL PAN T ATF RTV (MS-GF41) 3 - OIL FILTER Fig. 157 Solenoid/Pressure Switch Assembly and Gasket 1 - SOLENOID/PRESSURE SWITCH ASSEMBLY RS 40TE AUTOMATIC TRANSAXLE 21 - 169 40TE AUTOMATIC TRANSAXLE (Continued) |
