(14) Measure input shaft end play. Place transaxle so input shaft is vertical. Set up end play set and (15) Remove oil pump-to-case bolts (Fig. 33). CAUTION: Be sure input speed sensor is removed (16) Install pullers Tool C-3752 as shown in (Fig. 34). Fig. 31 Low/Reverse Accumulator 1 - PISTON Fig. 32 Measure Input Shaft End Play Using End Play Set 8266 1 - TOOL 8266–8 Fig. 33 Remove Pump Attaching Bolts 1 - PUMP ATTACHING BOLTS Fig. 34 Install Tool C-3752 1 - PULLERS TOOL C-3752 21 - 330 41TE AUTOMATIC TRANSAXLE PT 41TE AUTOMATIC TRANSAXLE (Continued) |
